Plan #1012

Description

This 2 bedroom ranch is designed with a vaulted and open living area wrapped around the covered deck. The bedrooms are separated with the bath and utilities located in the Master wing and French doors off the foyer for an office or den option at bedroom #2.

Floor Plan

Heated Area

1012 sq. ft

Roof

Truss
6/12 main pitch
8/12 front pitch

Floor

Truss or TJI

Walls

8' plates
L=148' (insulated)

Ceilings

Vaulted - Living, Dining,
Kitchen, Foyer & MBR

Basement

Approx. 914 sq. ft
View-out

(Opt'l Finish)

Rec room
2 Bedrooms
Full Bath

Masonry

Approx. 200 sq. ft
Front only (Includes
front offsets)

Kitchen

Approx. 11' x 10'
Base cabs L=14'
Upper cabs L=13'

Misc

Csmt windows
Gas log Fireplace
